Functional Groups

● Benthos - Bottom-dwelling organisms

● Detritus - Organic matter

● Fish - Fish species

● Phytoplankton - Primary producers

● Zooplankton - Small drifting organisms

Ecological Interaction Network Explorer

Quick Start

  1. Food Web Network: Explore the interactive network visualization
  2. Topological Metrics: View structural properties of the food web
  3. Biomass Analysis: Examine biomass-weighted metrics
  4. Energy Fluxes: Analyze energy flow patterns

Click on the sidebar menu items to navigate!

🌊 Welcome to EcoNeTool - Marine Food Web Network Analysis Tool

Interactive Shiny Dashboard for analyzing trophic interactions, biomass distributions, and energy fluxes in marine ecosystems


📊 Analysis Features

🕸️ Network Visualization
  • Interactive Graphs: Force-directed and trophic-level layouts with zoom/pan
  • Color Coding: By functional groups (Benthos, Detritus, Fish, Phytoplankton, Zooplankton)
  • Node Sizing: Proportional to species biomass
  • Edge Weights: Interaction strength or energy flux visualization
📈 Topological Metrics
  • trophiclevels() - Iterative calculation of trophic positions
  • get_topological_indicators() - Network structure analysis (S, C, G, V, TL, Omnivory)
  • Species Richness: Total number of taxa in the food web
  • Connectance: Proportion of realized trophic links
  • Generality & Vulnerability: Mean prey/predator counts
⚖️ Biomass-Weighted Analysis
  • get_node_weighted_indicators() - Quantitative metrics accounting for biomass
  • Node-Weighted Connectance: Biomass-adjusted link density
  • Node-Weighted Generality/Vulnerability: Importance-scaled feeding patterns
  • Biomass Distributions: Size spectrum and functional group analysis
⚡ Energy Flux Analysis
  • calculate_losses() - Metabolic losses via allometric scaling
    Brown et al. (2004) 'Toward a metabolic theory of ecology', Ecology
  • get_fluxweb_results() - Energy flux calculations using metabolic theory
    Gauzens et al. (2019) 'fluxweb: An R package to easily estimate energy fluxes in food webs', Methods in Ecology and Evolution
  • fluxind() - Link-weighted indicators (lwC, lwG, lwV) via Shannon diversity
    Bersier et al. (2002) 'Quantitative descriptors of food web matrices', Ecology
  • Temperature-Adjusted: T=3.5°C for Gulf of Riga conditions
    Gillooly et al. (2001) 'Effects of size and temperature on metabolic rate', Science
  • Flux Units: kJ/day/km² with log-scale visualization
    Barnes et al. (2018) 'Energy flux: The link between multitrophic biodiversity and ecosystem functioning', Trends in Ecology & Evolution
🔑 Keystone Species Identification
  • calculate_mti() - Mixed Trophic Impact matrix (ECOPATH method)
  • calculate_keystoneness() - Keystoneness index (Libralato et al. 2006)
  • Species Classification: Keystone, Dominant, Other or Undefined
  • Impact Visualization: Heatmaps showing direct & indirect effects
  • Reference: Libralato et al. (2006), Ecological Modelling
🎨 Visualization Functions
  • plotfw() - Food web plotting with trophic level layout
  • Interactive Networks: visNetwork integration with hover tooltips
  • Static Plots: Publication-quality figures with ggplot2-style
  • Export Options: Download plots and data tables

📊 Current Dataset

  • Source: Gulf of Riga food web (Frelat & Kortsch, 2020)
  • Location: Baltic Sea, Gulf of Riga
  • Period: 1979-2016 (37 years)
  • Taxa: 34 species across 5 functional groups
  • Links: 207 trophic interactions
  • Data Type: Temporally-averaged food web

🚀 Getting Started

  1. Explore the Network: Navigate to Food Web Network tab to see interactive visualization
  2. View Metrics: Check Topological Metrics for structural properties
  3. Analyze Biomass: Visit Biomass Analysis for node-weighted indicators
  4. Energy Flows: Examine Energy Fluxes for metabolic theory-based calculations
  5. Find Keystones: Use Keystoneness Analysis to identify key species
  6. Import Data: Upload your own food web via Data Import tab

📝 Version 1.7.10 - Survey Completeness
Released: 2026-10-21
• 4 new database integrations (SeaLifeBase, freshwaterecology.info, AlgaeBase, SHARK)
• Detailed progress tracking for automated trait lookup
• Dedicated Automated Lookup tab with comprehensive database info
• Centralized version management system

Scientific Foundations: Brown et al. (2004) • Bersier et al. (2002) • Libralato et al. (2006) • Williams & Martinez (2004) • Gauzens et al. (2019)


Export Current Metaweb

Export the currently loaded metaweb to RDA format (compatible with BalticFW.Rdata structure).


Format: Frelat & Kortsch (BalticFW.Rdata compatible)

Exported File Structure:
  • net: igraph network object with trophic interactions
  • info: species data frame with:
    • species, functional group (fg), biomass (meanB)
    • body masses, metabolic types, efficiencies
    • taxon, organism type, metabolic losses

The exported file can be re-imported using 'Upload Your Data' or loaded with load('my_metaweb.Rdata') in R.


Upload Your Data

Maximum file size: 10 MB




Data Validation

Data Requirements:
  • ✓ Species names must match between network and info
  • ✓ Network must be square (same row/column names)
  • ✓ Biomass values must be positive
  • ✓ Functional groups should be consistent
  • ✓ Losses and efficiencies: 0-1 range
  • ✓ At least 3 species recommended
After Upload:

Once your data is loaded, all analysis tabs will automatically use your uploaded data.

Reset to Default:

Refresh the page to reload the default Gulf of Riga dataset.


Import ECOPATH Native Database

Enter sampling location coordinates:

Required: the habitat layer is loaded around this point at import



Import ECOPATH CSV/Excel Exports

Alternative: Import Exported Files

Upload CSV/Excel exports from ECOPATH. Recommended for Windows users.





ECOPATH Export Guide

Required Files from ECOPATH
1. Basic Estimates

Export: File → Export → Basic Estimates

Required columns:

  • Group name - Species/group name
  • Biomass - Biomass (t/km²)
  • P/B - Production/Biomass ratio
  • Q/B - Consumption/Biomass ratio
2. Diet Composition

Export: File → Export → Diet Composition

Matrix format:

  • Rows = Prey species
  • Columns = Predator species
  • Values = Diet proportion (0-1)

Supported File Formats

1. Excel Format (.xlsx, .xls)

Excel files should contain the following sheets:

Sheet 1: Network (Adjacency Matrix)

A square matrix where rows and columns represent species:

Species_ASpecies_BSpecies_C
Species_A010
Species_B001
Species_C000

Rows = prey, columns = predators: a 1 in row A, column B means B eats A (edge A → B, prey → predator). Here B eats A and C eats B.

Sheet 2: Species_Info

Species attributes (one row per species):

speciesfgmeanBlossesefficiencies
Species_APhytoplankton2100.00.050.40
Species_BZooplankton850.20.080.75
Species_CFish1250.50.120.85
Required Columns:
  • species: Species name (must match network row/column names)
  • fg: Functional group (e.g., Fish, Benthos, Phytoplankton, Zooplankton, Detritus)
  • meanB: Mean biomass (g/km² or your preferred unit)
  • losses: Metabolic losses (J/sec) for flux calculations
  • efficiencies: Assimilation efficiencies (0-1) for flux calculations
Optional Columns:
  • bodymasses: Average body mass (g)
  • taxon: Taxonomic classification
  • nbY: Number of years recorded

2. CSV Format (.csv)

Two CSV files required:

File 1: network.csv (Adjacency Matrix)
species,Species_A,Species_B,Species_C
Species_A,0,1,0
Species_B,0,0,1
Species_C,0,0,0
File 2: species_info.csv
species,fg,meanB,losses,efficiencies
Species_A,Phytoplankton,2100.0,0.05,0.40
Species_B,Zooplankton,850.2,0.08,0.75
Species_C,Fish,1250.5,0.12,0.85

3. RData Format (.Rdata, .rda)

R workspace containing two objects:

  • net: igraph object with food web network
  • info: data.frame with species information (columns as above)

Example R code to create:

library(igraph)

# Create adjacency matrix: rows = prey, columns = predators (B eats A, C eats B)
adj_matrix <- matrix(c(0,1,0, 0,0,1, 0,0,0), nrow=3, byrow=TRUE)
rownames(adj_matrix) <- colnames(adj_matrix) <- c('Species_A', 'Species_B', 'Species_C')

# Create network
net <- graph_from_adjacency_matrix(adj_matrix, mode='directed')

# Create species info
info <- data.frame(
  species = c('Species_A', 'Species_B', 'Species_C'),
  fg = factor(c('Phytoplankton', 'Zooplankton', 'Fish')),
  meanB = c(2100.0, 850.2, 1250.5),
  losses = c(0.05, 0.08, 0.12),
  efficiencies = c(0.40, 0.75, 0.85)
)

# Save
save(net, info, file='my_foodweb.Rdata')

Example Datasets

1. Simple 3-Species Chain

Perfect for testing - basic linear food chain

  • 3 species (Phytoplankton → Zooplankton → Fish)
  • 2 trophic links
  • Ideal for learning the format
Download RData Network CSV Info CSV
2. Caribbean Reef

Realistic tropical reef food web

  • 10 species across 4 functional groups
  • 18 trophic interactions
  • Multiple trophic levels
Download RData Network CSV Info CSV
3. Empty Template

Start from scratch with proper structure

  • 3 placeholder species
  • Correct file format
  • Modify for your own data
Download RData Network CSV Info CSV

How to Use Example Files:
  1. Download one of the example RData files above
  2. Upload it using the file input above
  3. Click 'Load Data' button
  4. Explore the food web in other tabs
File Formats:

RData: Ready to upload directly to EcoNeTool
CSV files: Open in Excel to view/modify structure (2 files needed: network + info)

See the examples/README.md file for detailed format documentation.


Interactive Food Web Network

Basal Species




Top Predators




Adjacency Matrix Heatmap

Topological Indicators (Qualitative Metrics)

These metrics describe the structural properties of the food web network without considering node weights (biomass).

  • S: Species richness (number of taxa)
  • C: Connectance (proportion of realized links)
  • G: Generality (mean number of prey per predator)
  • V: Vulnerability (mean number of predators per prey)
  • ShortPath: Mean shortest path length
  • TL: Mean trophic level
  • Omni: Omnivory index (mean SD of prey trophic levels)

Calculated Metrics




Food Web with Biomass-Scaled Nodes

Interactive network visualization with node sizes representing biomass (logarithmic scaling). Nodes are arranged hierarchically by precise trophic level: highest trophic levels at the top, lowest at the bottom. Minor differences in trophic level are visible through vertical positioning.


Biomass Distribution by Functional Group

Box plot showing biomass distribution across functional groups.

Biomass Percentage by Functional Group

Relative contribution of each functional group to total biomass.


Node-weighted Indicators (Quantitative Metrics)

These metrics account for the relative importance of species based on their biomass.

  • nwC: Node-weighted connectance - weighted measure of network connectivity
  • nwG: Node-weighted generality - average number of prey per predator, weighted by biomass
  • nwV: Node-weighted vulnerability - average number of predators per prey, weighted by biomass
  • nwTL: Node-weighted mean trophic level - average trophic position weighted by biomass



Energy Flux Analysis

Energy fluxes are calculated using metabolic theory of ecology. Fluxes represent biomass flow between species based on allometric scaling and temperature-adjusted metabolic rates (T=3.5°C, Gulf of Riga spring conditions).

Units: kJ/day/km²

Note: Flux values span many orders of magnitude (10-10 to 10-1), reflecting the wide range of interaction strengths in the food web.


Flux-weighted Network

Edge widths proportional to energy flux magnitude. Hover over edges to see exact values.


Flux Matrix Heatmap (Log-transformed)

Color intensity shows log-transformed flux values. Darker colors indicate stronger energy flows.


Link-weighted Flux Indicators

Shannon diversity indices calculated from energy flux distributions.

  • Flux diversity: Distribution evenness of energy flows
  • Effective number of fluxes: Equivalent number of equally strong flows



Keystoneness Analysis (ECOPATH Method)

Identifying Keystone Species

Keystoneness analysis identifies species with disproportionately large effects on ecosystem structure and function relative to their biomass. This analysis follows the ECOPATH methodology using Mixed Trophic Impact (MTI) calculations.

Key Concepts:
  • Mixed Trophic Impact (MTI): net effect (direct + indirect) of a small increase of one species on every other (Ulanowicz & Puccia 1990). Producers show positive impacts on their consumers, and predators negative impacts on their prey.
  • Overall Effect (ε): sqrt of the sum of squared MTI values of a species on all others (its own self-impact excluded)
  • Keystoneness Index (KS): log10(ε × (1 - p)), where p is the species' share of total biomass (Libralato et al. 2006; base-10 log, as reported by EwE). Higher KS = larger impact for its biomass.
Species Classifications:
  • Keystone: KS in the top quartile of the web and biomass < 5% of total
  • Dominant: KS in the top quartile and biomass ≥ 5% of total
  • Other: every other species with a defined KS
  • Undefined: KS cannot be computed (no impact, missing (NA) biomass, or the only biomass in the web)
Approximations used when EwE data are missing:
  • Without Q/B (consumption/biomass), predation pressure on a prey is apportioned by predator biomass instead of predator consumption (B × Q/B).
  • Without diet proportions (e.g. binary metawebs and trait-based webs), each predator's diet is split equally among its prey.
  • Detritus is treated as an ordinary prey; EwE routes it through detritus fate, so impacts on and of detritus are indicative only.

Reference: Libralato et al. (2006). Ecological Modelling, 195(3-4), 153-171.

Keystoneness Index Rankings

Species ranked by keystoneness index (highest to lowest)

Keystoneness vs Biomass Plot

Keystone species appear top-left: KS above the dashed top-quartile line, biomass left of 5%

Mixed Trophic Impact (MTI) Heatmap

How to read:

  • Rows = Impacting species (impactor)
  • Columns = Impacted species
  • The diagonal (self-impact) is left blank
  • Red = Negative impact (impactor decreases impacted)
  • Blue = Positive impact (impactor increases impacted)
  • Values represent net effect through direct and indirect pathways

Top Keystone Species Details




Network Comparison

Place two food webs side by side and see how they differ: before/after a perturbation, two regions, or an ECOPATH model against a trait-built web.

  1. Load the first web through Data Import (or pick a bundled example) and store it as Network A.
  2. Load the second web and store it as Network B.
  3. The tables below update automatically. Deltas are always B − A.

Species are matched by name (case and surrounding whitespace ignored). Links are compared among shared species only; links touching a species the other web lacks are counted separately.

Network A

or




Network B

or




Topological indicators

S species richness, C connectance, G generality, V vulnerability, ShortPath mean shortest path, TL mean trophic level, Omni omnivory. nw* rows are biomass-weighted and appear only when both webs carry meanB.

Species composition




Trophic links among shared species

Shared species: prey, predators and trophic level

Internal Data Editor

Edit Internal Datasheets

This tab allows you to directly edit the two main internal datasheets:

  • Species Information: Species attributes including biomass, functional groups, body masses, and metabolic parameters
  • Network Adjacency Matrix: The food web structure showing who eats whom

Note: Changes are applied in real-time. Use the 'Update Network' button to refresh all visualizations after editing.

Edit species attributes. Double-click cells to edit values.

Required columns: meanB, fg, bodymasses, met.types, efficiencies

Column Descriptions (click to expand)
  • species: Species name or identifier
  • meanB: Mean biomass of the species (g/km²)
  • fg: Functional group (Fish, Benthos, Phytoplankton, Zooplankton, Detritus)
  • bodymasses: Average body mass of individual organism (grams)
  • met.types: Metabolic type (invertebrates, ectotherm vertebrates, Other)
  • efficiencies: Assimilation efficiency (0-1, proportion of consumed energy assimilated)
  • taxon: Taxonomic classification
  • nbY: Number of years recorded in the dataset
  • losses: Metabolic losses (J/sec) calculated from body mass and temperature
  • org.type: Organism type classification




Edit the food web structure. Values should be 0 (no interaction) or 1 (the column species eats the row species).

Tip: Hover over species names (underlined) to see their role in the food web.

Rows = Prey, Columns = Predators. Value of 1 in row i, column j means species j eats species i (edge i → j, prey → predator).





Metaweb Manager

Regional Metaweb Management

MARBEFES WP3.2 Phase 2: Assemble and manage regional metawebs for ecological interaction network analysis.

A metaweb contains all documented species and trophic interactions in a region, serving as the basis for extracting local food webs.

  • Load: Import pre-built regional metawebs or custom CSV files
  • View: Visualize metaweb structure and browse species/interactions
  • Edit: Add/remove species and trophic links
  • Quality: Assess link evidence quality (1-4 scale)
  • Export: Download metawebs in CSV or RDS format

Pre-built Regional Metawebs

Load metawebs from published literature sources (MARBEFES guidance):


Note: Some metawebs require download from literature sources. See metawebs/README.md for details.

Import Custom Metaweb

Upload your own metaweb from CSV files:


Use template files in metawebs/ folder as examples. Each interactions row means predator_id eats prey_id; the network drawn from it points prey → predator (direction of energy flow).

Current Metaweb Summary




Metaweb Network Visualization

Interactive visualization of all species and trophic interactions in the metaweb:

Species List

All species in the metaweb:

Trophic Interactions

All documented feeding links:

Add Species


Remove Species

Add Trophic Link


Remove Trophic Link

Edit Status




Link Quality Distribution

Quality Summary Table

Link Quality Guidelines

MARBEFES Quality Code Definitions:
  • 1: Documented - Peer-reviewed literature for these exact species
    Example: Gut content analysis published for this predator-prey pair
  • 2: Similar species - Documented for similar species or different region
    Example: Same predator, similar prey species documented elsewhere
  • 3: Inferred - Inferred from traits or body size relationships
    Example: Predator and prey body sizes suggest potential link
  • 4: Expert opinion - Expert judgment, not yet validated
    Example: Regional expert suggests link based on experience

Filter by Quality

Export Metaweb

Download the current metaweb for sharing or backup:

Download Metaweb

CSV format: Creates two files (species and interactions) compatible with Excel and other tools.

RDS format: Single R object file preserving all metadata, ideal for R users.

Use Metaweb for Analysis

Convert the current metaweb to an active network for analysis in other tabs:


This will convert the metaweb to an igraph network object and make it available for topological metrics, biomass analysis, energy fluxes, and keystoneness analysis.




Trait Research - Query species traits from online databases

Species Input
One species per line or 'species' column
Actions

Use scientific names
Databases

Species List

Species to be looked up:


Lookup Status


Progress Summary

Lookup Progress

Real-time progress of database queries.


Trait Summary

Species Found
Complete Traits
Partial Traits
Not Found

Found Traits Table

View trait data retrieved from databases. Click column headers to sort.


Badge Legend
FishBase SeaLifeBase WoRMS BIOTIC PTDB MAREDAT OfflineDB ML Taxonomy Depth BlackSea Arctic Cefas Coral

Raw Trait Details

Detailed raw data from database queries (before harmonization).


MS - Maximum Size

Code Size Range Examples
MS1 < 0.1 cm Bacteria, small phytoplankton
MS2 0.1 - 0.5 cm Copepods, rotifers
MS3 0.5 - 1 cm Small amphipods, mysids
MS4 1 - 3 cm Shrimps, small fish larvae
MS5 3 - 10 cm Small fish, crabs
MS6 10 - 50 cm Medium fish, lobsters
MS7 > 50 cm Large fish, seals

FS - Foraging Strategy

Code Strategy Examples
FS0 Primary producer / none Phytoplankton, diatoms, macroalgae
FS1 Predator / Carnivore Active hunters: piscivorous fish, cephalopods
FS2 Scavenger / Detritivore Carrion feeders, detritus feeders
FS3 Omnivore Mixed-diet generalists
FS4 Grazer / Herbivore Algae scrapers, browsers, herbivorous fish
FS5 Deposit feeder Sediment-ingesting infauna, lugworms
FS6 Filter / Suspension feeder Bivalves, planktivorous fish, sponges
FS7 Xylophagous Wood-borers: shipworms (Teredinidae), gribbles

MB - Mobility

Code Mobility Examples
MB1 Sessile Barnacles, mussels, sponges, sea anemones, hydroid colonies
MB2 Passive floater / drifter Phytoplankton, jellyfish, salps, ctenophores
MB3 Crawler-burrower Crabs, sea stars, snails, lugworms, burrowing clams
MB4 Facultative / limited swimmer Flatfish, shrimp, mysids
MB5 Obligate swimmer Most fish, squid, marine mammals

EP - Ecosystem Position

Code Position Description
EP1 Pelagic Water column, no substrate contact
EP2 Benthopelagic Near the bottom, swims in the water column
EP3 Epibenthic On the sediment or rock surface (incl. attached and tube-dwelling taxa)
EP4 Endobenthic / Infaunal Within the sediment (burrowing)

PR - Protection

Code Protection Examples
PR0 None / Soft body Jellyfish, naked sea slugs, most fish
PR1 Mucus / Cuticle Hagfish, sea cucumbers, some larvae
PR2 Tube Tube worms (Polychaeta), serpulids
PR3 Burrow refuge Burrowing shrimp, permanent-burrow dwellers
PR4 Thin exoskeleton Copepods, amphipods, small arthropods
PR5 Soft shell Moulting crabs, juvenile bivalves
PR6 Hard shell Mussels, snails, barnacles
PR7 Spines / ossicle plates Sea urchins, sea stars, brittle stars, sponges
PR8 Armoured Crabs, lobsters, sturgeon

RS - Reproductive Strategy

Code Strategy Examples
RS1 Broadcast spawner Most pelagic fish, sea urchins, mussels
RS2 Brooder / direct developer Sharks, gobies, peracarid crustaceans
RS3 Asexual / budding / fission Many cnidarians, some annelids
RS4 Mixed / sequential strategy Hermaphroditic fish, alternating-generation cnidarians

TT - Temperature Tolerance

Code Tolerance Examples
TT1 Cold-stenothermal Arctic / polar specialists
TT2 Cold-eurythermal Boreal, subarctic species
TT3 Warm-eurythermal Temperate cosmopolitans
TT4 Warm-stenothermal Tropical / subtropical specialists

ST - Salinity Tolerance

Code Tolerance Examples
ST1 Freshwater Limnetic species
ST2 Oligohaline Brackish, low salinity (0.5-5 PSU)
ST3 Mesohaline Brackish, intermediate (5-18 PSU)
ST4 Polyhaline Marine-brackish (18-30 PSU)
ST5 Euhaline Full marine salinity (>30 PSU)

About Trait Harmonization

Raw trait data from databases is automatically converted to these categorical codes based on the following rules:

  • Size (MS): Derived from maximum body length/size measurements
  • Foraging (FS): Inferred from trophic level, diet composition, and feeding type
  • Mobility (MB): Based on locomotion type and attachment status
  • Position (EP): Determined from habitat depth and substrate association
  • Protection (PR): Assessed from body covering and defensive structures

Trait Profile Visualization

Radar chart showing all 8 trait categories as a normalized profile.

Offline Trait Database


Re-populates the offline database. May take several minutes.

DATRAS Abundance Indices

Queries the ICES DATRAS trawl surveys BITS, NS-IBTS and BTS for the most recent year with computed indices. Values are raw abundance indices (numbers-per-hour, summed across ages) per stock-area — not biomass, and not calibrated for Ecopath. Run a trait lookup first to populate the species list.

Food Web Construction

Construct trait-based food webs using interaction probability matrices. Edit traits, validate data, and visualize the resulting network.



Data Source

Trait Codes
MS:
Size (MS1-MS7)
FS:
Foraging (FS0-FS7)
MB:
Mobility (MB1-MB5)
EP:
Position (EP1-EP4)
PR:
Protection (PR0-PR8)

Use Data from Trait Research

Load trait data that was looked up in the Trait Research module.

If no data is available, first use the Trait Research module to look up species traits.

Upload CSV File

Upload a CSV file with species trait data.

Required Format:
species,MS,FS,MB,EP,PR
Gadus morhua,MS6,FS1,MB5,EP4,PR0
...
Download Template CSV

Example Datasets

Load a pre-built example dataset.

Manual Entry

Create a blank template for manual trait entry.

Create template, then edit in the 'Trait Editor' tab.
Data Status

Workflow
  1. Load or enter trait data
  2. Edit traits in 'Trait Editor'
  3. Validate data quality
  4. Construct network in 'Network'

Edit and Validate Species Trait Data

Species Trait Table
Click any cell to edit. Changes are saved automatically.

Validation Results
Dataset Statistics
Trait Distribution

Food Web Network Construction and Visualization

Network Parameters
Higher = fewer interactions (more restrictive)

Download Adjacency Matrix Download Network (RDS) Download Network (GraphML)
Network Properties
Food Web Network
Drag nodes to rearrange. Zoom with mouse wheel. Click nodes for details.
Interaction Probability Heatmap
Color intensity indicates interaction probability.

Interaction Probability Matrices

These matrices define the probability of interaction given trait combinations.


Consumer Size x Resource Size

Probability that a consumer of size MSi can consume a resource of size MSj.

  • Diagonal (0.5): Cannibalism or same-size predation
  • Below diagonal (0.0): Smaller cannot eat larger
  • Above diagonal: Probability decreases with size difference

Consumer Foraging Strategy x Resource Size

Probability that a consumer with foraging strategy FSi can access a resource of size MSj.


Consumer Mobility x Resource Mobility

Probability that a consumer with mobility MBi can capture a resource with mobility MBj.


Consumer Position x Resource Size

Probability that a consumer in position EPi can access a resource of size MSj.


Resource Protection x Consumer Size

Probability that a consumer of size MSi can overcome protection PRj.

Phase 1: Spatial Analysis (BBT Support)

Spatial Food Web Analysis

Create hexagonal grids, assign species to spatial units, extract local networks, and calculate spatial metrics following MARBEFES WP3.2 guidelines.

Define Study Area Boundary

Upload a shapefile/GeoPackage or select a BBT polygon to define your study area. The hexagonal grid will be clipped to this boundary.





Study Area Preview


Note: If no study area is provided, the grid will cover the entire bounding box specified in Step 1.

Configure Hexagonal Grid

Configure your spatial grid (1-3km hexagons recommended for BBT)




EMODnet Habitat Integration

Integrate EMODnet EUSeaMap habitat data with your spatial grid.

What this does:

  • Automatically loads regional habitat data (bbox-filtered for your area)
  • Clips habitat map to your study area boundary
  • Overlays habitat polygons with hexagonal grid cells
  • Calculates habitat statistics for each grid cell
  • Adds EUNIS codes, substrate types, and diversity metrics

Note: Habitat loads a small centered area for reliability (avoids data errors). Click 'Clip Habitat to Study Area' button below to get full coverage.

Note: Loads small test area initially. Click 'Clip Habitat' for full coverage.
Grid Cell Attributes Added:
  • dominant_eunis: Most common EUNIS code
  • dominant_habitat: Habitat description
  • dominant_substrate: Main substrate type
  • habitat_diversity: Shannon diversity of EUNIS codes
  • n_habitats: Number of different habitats
  • habitat_area_km2: Total habitat area in cell
  • substrate_*_pct: Percentage of each substrate

Habitat Processing Status




Upload or Generate Species Data

Upload or generate species occurrence data (CSV with lon, lat, species columns)

Extract Local Networks from Metaweb

Select metaweb and extract local networks for each hexagon




Calculate Food Web Metrics

Calculate food web metrics for each hexagon

Interactive Map

Visualize spatial metrics on interactive map (requires calculated metrics)


Map Layers: Study Area (blue), Grid (gray), Species (green), Metrics (color)

Export Results

Download Metrics (CSV) Download Full Analysis (RDS)
Download spatial metrics table or complete spatial_foodweb_data object for further analysis in R.

EcoBase - Online Ecopath Model Repository

Connect to EcoBase Web Service

EcoBase is an online repository of Ecopath with Ecosim (EwE) models from around the world.

Website: http://sirs.agrocampus-ouest.fr/EcoBase/

Use this interface to browse and download published Ecopath models directly into EcoNeTool.

1. Browse Available Models




2. Model Details


Hybrid: Balanced parameters (Output) + Complete diet links (Input) - Recommended!
Output: Mass-balanced, may lack diet data for some models
Input: Original parameters with complete diet composition






Requirements

Required R Packages

EcoBase connection requires additional packages:

install.packages(c('RCurl', 'XML', 'plyr', 'dplyr'))
Internet Connection

Active internet connection required to access EcoBase web service.

Model Types
  • Output (Balanced): Mass-balanced parameters from EwE output
  • Input (Original): Original input parameters before balancing
What Gets Imported
  • Species/functional groups
  • Biomass values
  • P/B ratios (Production/Biomass)
  • Q/B ratios (Consumption/Biomass)
  • Ecotrophic efficiency (EE)
  • Diet composition (trophic links)

SHARK4R - Swedish Ocean Archives

Access Swedish Marine Environmental Data

SHARK (Svenskt HavsARKiv) is Sweden's national database for marine environmental monitoring data, maintained by SMHI (Swedish Meteorological and Hydrological Institute).

This interface provides access to:

  • Taxonomy: WoRMS; Dyntaxa (Swedish species) and AlgaeBase need subscription keys
  • Environmental Data: Temperature, salinity, nutrients, oxygen from 1900s-present
  • Species Occurrence: Biological records (plankton, benthos, seals)
  • Quality Control: Validate SHARK format data files

Documentation: SHARK4R Package | SHARK Database

‌


Search Species Taxonomy

Not configured on this server (no subscription key): Dyntaxa (DYNTAXA_KEY), AlgaeBase (ALGAEBASE_KEY)

Tip: Use scientific names. Dyntaxa also accepts Swedish names such as 'torsk' (cod) or 'sill' (herring).

Taxonomy Results


Query Environmental Data

to

Bounding Box (Optional)
Fill in all four fields, or leave all four blank for all Swedish waters
SHARK queries take 25-90 s and pause the app for all users; keep the area and year range small.

Environmental Data Results


Query Species Records

to
SHARK queries take 25-90 s and pause the app for all users; keep the area and year range small.
Note: SHARK matches the exact scientific name. It holds plankton, benthos and seal records; most fish are not in SHARK. Each row is one measured parameter (count, abundance, weight).

Species Records


Upload SHARK Format Data

Accepted formats: CSV, or tab-separated TXT/TSV
Expected structure: SHARK standard format



Quality Control Results





Requirements & Installation

Required R Package

This module requires the SHARK4R package, version 1.2.0 or newer:

install.packages('SHARK4R')
Optional subscription keys
  • DYNTAXA_KEY enables Dyntaxa (SLU Artdatabanken API).
  • ALGAEBASE_KEY enables AlgaeBase (AlgaeBase API subscription).

Set them in the server's .Renviron and restart the app.

Package Information
  • Version: 1.2.0+
  • License: MIT
  • Maintainer: SMHI (Swedish Meteorological and Hydrological Institute)
Documentation & Resources
Data Coverage
  • Temporal: 1900s - present (varies by parameter)
  • Spatial: Swedish waters (Baltic Sea, Skagerrak, Kattegat)
  • Parameters: 100+ environmental and biological variables

ECOPATH/ECOSIM Modeling

Run mass-balance models and dynamic simulations using the Rpath package (NOAA-EDAB)

Feedback Dashboard
